Trailers

Model TG1 GT1 GT2 TT1/ TT1BX* TT2 TT3 TT4
Body length 1,520mm (60″) 1,520mm (60″) 1,520mm (60″) 1,830mm (72″) 2,450mm (96″) 3,050mm (120″) 3,050mm (120″)
Body width 920mm (36″) 920mm (36″) 920mm (36″) 1,220mm (48″) 1,540mm (61″) 1,830mm (72″) 1,830mm (72″)
Total length 2,300mm (91″) 2,300mm (91″) 2,300mm (91″) 2,450mm (96″) 3,300mm (130″) 4,300mm (169″) 4,300mm (169″)
Weight 100kg 160kg 160kg 250kg 410kg 740kg 800kg
Capacity 500kg 500kg 750kg 1,250kg 2,00kg 3,500kg 3,500kg
Hydraulic Tip Manual Option Option Hydraulic Hydraulic Hydraulic Hydraulic
Removable corner posts No Standard Standard Standard Standard Standard Standard
Removable hinged sides Fixed 300mm Std 300mm Std 300mm Std 355mm Std 355mm Std 460mm Std 460mm
Wheels 16 x 6.50-8 18 x 8.50-8 18 x 8.50-8 23 x 8.50-12 23 x 10.50-12 10/75-15 10/75-15

*TT1BX is only suitable for the BX models

Optional Equipment

Mesh sides 300mm 355mm 355mm 450mm 450mm 610mm 610mm
Parking brake no N/A N/A Option Option Option Standard
Road light kit N/A N/A N/A Option Option Option Standard
Overrun brake N/A N/A N/A N/A N/A N/A Standard
HD suspension N/A N/A N/A N/A N/A N/A Standard
